200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque

small crawler mounted water well drill

portable water well drilling machine with warranty

2000N.M torque water well drill rig

Lugar de origem:

China

Marca:

RanCheng

Certificação:

CE, ISO 9001:2000

Número do modelo:

RCS200C

Contacte-nos

Pedido Umas citações

Detalhes do produto

Diâmetro de perfuração:

100-300 mm

Torque máximo:

1000-2000N.M

Caminhando:

Esteira rolante montada

Garantia:

1 ano

Profundidade de perfuração:

100-200 metros

Peso:

200-500kg

Potência do motor a diesel:

22 CV / 16,2 kW

dept de perfuração:

80-150 m

Motor a diesel:

22HP

Aplicação:

perfuração de poços de água

Destacar:

small crawler mounted water well drill

portable water well drilling machine with warranty

2000N.M torque water well drill rig

Termos de pagamento e envio

Quantidade de ordem mínima

Preço

US $ 7000-8000

Detalhes da embalagem

Envio padrão

Tempo de entrega

10-15 dias úteis

Termos de pagamento

T/T, Western Union

Habilidade da fonte

100 grupos por mês

PRODUTOS CONEXOS

Vídeo

Profundidade máxima 200m RCS200C Máquina de perfuração de poços de água

Obtenha o melhor preço

Vídeo

Máquina de perfuração hidráulica de água para poços de irrigação de 150 m de profundidade

Obtenha o melhor preço

Vídeo

Easy Operation RCS200C Rubber Crawler Portable Drilling Rig With 150m Depth 450mm Diameter

Obtenha o melhor preço

Vídeo

200m Small Water Well Rock Drilling Rig With 2000KG Hosting Capacity

Obtenha o melhor preço

Contacte-nos

Contato agora

Descrição do produto

200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque

Product Description

Name: 200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: RCS200C
Price: 7,500.00 USD
Availability: InStock

The RCS200C is a compact water well drill rig equipped with a superior hydraulic propulsion system. This system provides stable torque to the drill string, reducing energy loss and enabling more precise drilling control. It features dual-mode operation with a mud pump and air compressor, offering flexible options for air, foam, or mud circulation to suit different formation types. Whether rotary or percussive drilling, this rig efficiently operates in a wide range of geological conditions, from soft soil and gravel to hard rock, with a drilling depth range of 0 to 200 meters. Its fully hydraulic configuration simplifies power transmission, reduces points of failure, and helps maintain stable progress on site.

Weighing approximately 2,000 kg and mounted on a rubber-tracked chassis, the RCS200C is easily towed by a standard pickup truck, eliminating the need for large transport vehicles and reducing logistics costs. Its diesel engine provides off-grid power, enabling operation in remote mountainous areas with limited electricity supply. Its size and maneuverability make it ideal for sites with narrow or restricted access. The drilling rig is widely used in water supply projects, agricultural irrigation wells, shallow geothermal facilities, exploration sampling wells, environmental monitoring wells and small-diameter micropile/foundation projects, providing versatile solutions for various site conditions.

Technical data

Model	RCS200C
Geology drilled	All kinds
Drill depth	200 m
Drilling Diameter	90 -300mm
Drill system and operation	Hydraulic
For rock	6-20F
Air consumption	17-35m³/min
Air pressure	1.7-3.0Mpa
Rotary head
Rotation Torque	4000-5000N.m
Rotation speed	80-200rpm
Lifting capacity	14000KGS
Pull down capacity	4000KGS
DRILL PIPE
Drill pipe length	2 meter
Drill pipe diameter	60/76/89 mm
MUD PUMP
Flow capacity	160 liter/min
working pressure	1.3MPA
DIMENSIONS
Transport size	230012001700mm
Weight	2000KGS
Diesel engine
Power	45KW Weifang Hengtong


200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque 0

200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque 1

200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque 2

200m Small Crawler Mounted Water Well Drill Rig 1000-2000N.M Torque 3
